Robotic Cell 2 - Crossbar Welding



Dual Axis Robotic Welding Cell purchased from Ford Motors utilising ABB Robots and Fronius Welders for reliable welding. A Crossbar can have single welds, double welds or cross stick welding for additional strength. The cell has a rotating turntable with jigs each side allowing for welding one side and unloading/loading the other side. The weld time is approximately 3.25 minutes per Crossbar.

​

Cell Details:

ABB 2400 Robots - 2x Robots - 1 Controller

IRC5 M2004 x 2 (2E2C2B)

Robot 1 Mechanical - IRB 2400 (Type - IRB2400L Type B, Serial 24-51611 Manufactured 2006)

Robot 2 Mechanical - IRB 2400 (Type - IRB2400L Type B, Serial 24-51615 Manufactured 2006)

Fronius TransPulse Synergic 4000 Mig Controller - Qty 2

Fronius Mig Torch and Wire Feeder x 2 (Orion RGOR Robots)

2x L Type Positioner, with ABB rollover interchange

Robacta TC 2000 Weld Tip Cleaner x 2

Cell Dimensions: 5.8m x 3.6m x 2.5m

​

Normal Crossbar:

​

​

​

​

​

​

​

​



​​​​​​​​​​​​​​​​​​​​​​​​​​​​​Centre Crossbar:

​

​
